Infusion Pump | Critical Care

Vital ZIP1
Infusion Pump

Compact and lightweight infusion pump with 4.3-inch color touch screen, audible and visual alarm system, built-in lithium battery (~5 hours), and multiple infusion modes for clinical requirements.

4.3" Color Touch Screen 5hr Battery Life Flow Rate 0.1–1500 ml/h

Key Features

✓4.3-inch color touch screen for easy operation and clear visibility
✓Compact and lightweight design for easy carrying and mounting
✓User-friendly interface with audible and visual alarm system
✓Built-in lithium battery — approximately 5 hours working time after full charge
✓Multiple infusion modes for different clinical requirements
✓Advanced pressure detection technology

Performance Specifications

Applicable Infusion Set	Various brands, single-use, 20 drops/ml, diameter 3.4–4.5mm
Infusion Modes	ml/h (flow rate & volume, flow rate & time, flow rate); d/min (drip & volume, drip & time, drip)
Flow Rate Range	0.1–1500 ml/h (0.1–100 ml/h in 0.1 increments; 101–1500 ml/h in 1 increment)
Infusion Dripping Speed	20–40 ml/h; infusion set: 1–500 d/min
Infusion Accuracy	±5%
VTBI	0.1–9999 ml
Purge Rate	1000 ml/h
KVO Rate	2.5 ml/h
